Schneider LC1D32 AC Control Power Contactor

Schneider LC1D32 AC Control Power Contactor Specification

Power Factor
0.7 min at 60 Hz

Operating Temperature
-5 to +60C

IP Rating
IP20

Humidity %
5-95% (non-condensing)

Overheating Protection
Provided via external relay

Mounting Type
DIN rail mounting

Connector Type
Screw clamp terminal

Insulation Material
Thermoplastic

Shape
Rectangular

Feature
Compact, reliable switching

Efficiency
High operational life

Surface Finish
Matte finish

Product Type
AC Control Power Contactor

Application
Electric

Protection Level
IP20

Frequency (MHz)
50/60 Hz

Rated Voltage
690 V AC

Energy Consumption
8.5 VA (Pick-up), 1.8 VA (Hold)

Output Type
Normally Open (NO), Normally Closed (NC)

Color
Black

Dimension (L*W*H)
77 x 45 x 86 mm

Weight
0.51 kg

Warranty
Yes

Size
D32 frame

Phase
Three Phase

Input Voltage
230 V AC

Connection Type
Screw terminal

No Of Poles
3 Pole

Material
High grade plastic, copper

Mechanical Life
10 million ops

Reference
LC1D32

Coil Consumption
3.3W

Electrical Life
1.3 million ops

Breaking Capacity
Rated IEC 60947

Auxiliary Contacts
1 NO + 1 NC

Control Voltage
24-415 V AC

RoHS Compliance
Yes

Schneider LC1D32 AC Control Power Contactor Trade Information

Minimum Order Quantity
5 Units

Payment Terms
Cash Advance (CA), Cash in Advance (CID)

Supply Ability
1000 Units Per Month

Delivery Time
7 Days

Main Export Market(s)
Asia

Main Domestic Market
All India

About Schneider LC1D32 AC Control Power Contactor

Schneider LC1D32 AC Control Power Contactor is a three-pole device with a current rating of up to 32A. It is suitable for use in various applications, including motor control, heating, and lighting. The contactor is equipped with an auxiliary contact block, which allows for remote indication of contactor status and facilitates interlocking with other devices. Our offered contactor is an AC control power contactor designed for switching and controlling electrical circuits in low voltage applications up to 690V AC. Moreover, this is manufactured by Schneider Electric, a leading company in the production of electrical equipment.

Product Details :

Country of Origin	Made in India
Brand	Schneider
Model Name/Number	LC1D32
Voltage	LC1D32
Switching Current	LC1D32
Number Of Poles	LC1D32

Innovative Design and Robust Construction

The Schneider LC1D32 is crafted from high-quality thermoplastic and copper, ensuring resilience in industrial environments. Its compact, rectangular D32 frame is finished in a matte coat and provides straightforward integration due to its progressive DIN rail mounting and screw clamp terminals. The IP20 rating, along with a protection level suited for demanding electric applications, maximizes operational safety.

Unmatched Reliability and Longevity

Engineered for endurance, this contactor boasts a mechanical life of 10 million operations and an electrical life reaching 1.3 million cycles. Its energy-efficient coil reduces consumption to just 1.8 VA when holding, minimizing operational costs. Compliance with RoHS and IEC 60947 underscores its commitment to quality and environmental standards.

Flexible Operation and Versatile Application

Thanks to a control voltage range from 24 to 415 V AC and compatibility with 50/60 Hz frequencies, the contactor adapts easily to various systems. The inclusion of both NO and NC auxiliary contacts enables broad usage possibilities in electric control panels and automation processes, making it an asset to dealers, distributors, and industrial users across India.

FAQ's of Schneider LC1D32 AC Control Power Contactor:

Q: How is the Schneider LC1D32 contactor installed in an electrical panel?

A: The LC1D32 is designed for easy DIN rail mounting, allowing quick installation in standard electrical panels. It uses screw clamp terminals for secure and reliable wiring connections, simplifying the setup process for both new and upgraded systems.

Q: What are the main benefits of using this power contactor in industrial applications?

A: This contactor offers high operational life, compact design, efficient energy consumption, and versatile voltage compatibility. Its robust construction ensures reliability, while the mechanical and electrical endurance makes it ideal for continuous and demanding industrial use.

Q: When should I replace or check the contactor for maintenance?

A: With a mechanical life of 10 million operations and an electrical life of 1.3 million cycles, routine visual inspections are recommended during scheduled maintenance. Replace the contactor if you observe signs of worn contacts, abnormal heating, or if the device doesn't switch reliably.

Q: Where can I purchase the Schneider LC1D32 contactor in India?

A: You can acquire the LC1D32 from authorized dealers, distributors, manufacturers, suppliers, traders, and wholesalers across India. Ensure you buy from recognized sources to receive a genuine product with warranty support.

Q: What is the process for wiring the auxiliary contacts of the LC1D32?

A: The LC1D32 includes 1 Normally Open (NO) and 1 Normally Closed (NC) auxiliary contact. Wiring is done via the screw clamp terminals, following your control circuit requirements. Refer to the product manual for proper auxiliary contact integration to ensure safe operation.

Q: How does the built-in protection feature work for this contactor?

A: Although the LC1D32 provides basic IP20 protection for touch safety, overheating protection is achieved through the use of an external relay. This relay monitors operational temperature and disconnects the circuit to protect the contactor from damage due to excess heat.

Q: What type of loads and applications is this contactor suitable for?

A: The Schneider LC1D32 is tailored for electric motor control and general automation in three-phase systems, given its 3-pole configuration and rated voltage up to 690V AC. Its robust design and reliable switching make it suitable for diverse industrial machinery, control panels, and automation equipment.
