LC1D40 AC Control Power Contactor

LC1D40 AC Control Power Contactor Specification

Feature
High Mechanical Durability, Compact Size, Easy Installation

Power Factor
>= 0.8

Operating Temperature
-5C to +60C

Shape
Cuboid / Rectangular

Connector Type
Screw Connector

Humidity %
95% RH (non-condensing)

Overheating Protection
No Built-in Overload Relay (use with external relay)

Insulation Material
Thermoplastic

Surface Finish
Matte Finish

IP Rating
IP20

Efficiency
High

Mounting Type
DIN Rail / Panel Mount

Product Type
AC Control Power Contactor

Application
Electrical

Protection Level
IEC 60947-4-1, AC3 Duty

Frequency (MHz)
50/60 Hz

Rated Voltage
690V AC

Energy Consumption
9 VA (pick-up), 1.7 VA (holding)

Output Type
Switching/Contactor

Color
Black

Dimension (L*W*H)
86 mm x 85 mm x 102 mm

Weight
0.76 kg

Warranty
Yes

Input Voltage
110V, 220V, 415V AC Coil Options

Phase
Three Phase

Size
Standard

No Of Poles
3

Connection Type
Screw Clamp, Front Connectivity

Material
High-grade Flame Retardant Plastic, Silver Alloy Contacts

Auxiliary Contacts
1 NO + 1 NC (optional)

Coil Consumption
9 VA (inrush), 1.8 VA (sealed)

Storage Temperature
-40C to +80C

Standards
IEC 60947-4-1, VDE 0660

Mechanical Life
10 million cycles

Altitude
up to 3000 m above sea level

Electrical Life
1.4 million operations at AC-3 duty

Main Contact Rating
40A (AC-3 up to 415V)

LC1D40 AC Control Power Contactor Trade Information

Minimum Order Quantity
5 Units

Payment Terms
Cash Advance (CA), Cash in Advance (CID)

Supply Ability
1000 Units Per Month

Delivery Time
7 Days

Main Export Market(s)
Asia

Main Domestic Market
All India

About LC1D40 AC Control Power Contactor

Discover a premier solution for your electrical control needs with the LC1D40 AC Control Power Contactor, now available at a sizzling sale price! Engineered for commanding performance, this contactor boasts a robust 40A rating at AC-3 duty (415V max), high mechanical life of 10 million cycles, and superior reliability in demanding environments. Its compact, cuboid design features high-grade flame-retardant plastic, silver alloy contacts, and a matte finish. Enjoy Instant Checkout and experience spectacular efficiency, meeting IEC and VDE standards, with flexible coil voltage options and easy installation. Warranty included!

Versatile Use and Application Media

The LC1D40 AC Control Power Contactor excels in commanding both heavy-duty industrial and commercial electrical setups. Specially designed for use with switching or contactor applications, it operates efficiently in three-phase environments. This compact device is suitable for application on panel surfaces, electric control panels, and MCC arrangements thanks to its flame-retardant and matte surface. Its robust construction and high electrical life ensure reliable operation with a variety of electrical media, making it ideal for engineers and technicians alike.

Efficient Packing, Dispatch, and Exchange Services

LC1D40 AC Control Power Contactor is supplied from premier domestic ports across India. Packing & Dispatch procedures prioritize safety, with proper protective covering to prevent damage during transit. With a strong supply ability nationwide, dealers, distributors, and suppliers benefit from prompt delivery and swift exchange services when needed. All related charges and documentation comply with Indian trade requirements to ensure a smooth and efficient procurement experience, making this product a top-tier choice for dependable electrical installations.

FAQ's of LC1D40 AC Control Power Contactor:

Q: How do I install the LC1D40 AC Control Power Contactor?

A: The LC1D40 contactor offers easy installation via either DIN rail or panel mounting. It features front connectivity and screw clamps for secure connections, making the process straightforward for both new and retrofitted electrical panels.

Q: What makes the LC1D40 suitable for demanding applications?

A: With a commanding 40A rating at AC-3 duty, premier mechanical durability (10 million cycles), and flame-retardant plastic body, the LC1D40 excels in both challenging industrial and commercial applications.

Q: Where can the LC1D40 AC Contactor be used in India?

A: It is widely supplied to various regions and main domestic markets across India, serving as a trusted choice for manufacturers, dealers, traders, and electrical contractors.

Q: When should I choose the LC1D40 for my installation?

A: Opt for the LC1D40 contactor when high reliability, long mechanical life, and compliance with IEC 60947-4-1 are required-ideal for new installations or as an efficient drop-in replacement.

Q: What is the energy consumption profile of this contactor?

A: The LC1D40 uses 9 VA during inrush and maintains a low holding consumption of 1.8 VA, ensuring economic and efficient long-term usage.

Q: Does the LC1D40 come with overload protection?

A: No, the contactor itself does not include a built-in overload relay. For overheating protection, an external relay should be used alongside the contactor.
