LC1D09 AC Control Power Contactor

LC1D09 AC Control Power Contactor Specification

Overheating Protection
Integrated

Feature
Low Power Consumption

Shape
Rectangular

Insulation Material
Thermoplastic

Surface Finish
Matte

Connector Type
Screw Type

Power Factor
0.8 min

Efficiency
High Switching Efficiency

Humidity %
95% RH max

IP Rating
IP20

Operating Temperature
-5C to +60C

Mounting Type
DIN Rail

Product Type
LC1D09 AC Control Power Contactor

Application
Electric

Protection Level
IP20

Frequency (MHz)
50/60 Hz

Rated Voltage
690V AC

Energy Consumption
3.5 VA (hold)

Output Type
NO/NC Contacts

Color
Black

Dimension (L*W*H)
45 x 80 x 85 mm

Weight
0.31 kg

Warranty
Yes

Phase
Three Phase

Input Voltage
230V AC Coil

Size
Standard

Connection Type
Screw Terminal

Material
Plastic and Metal

No Of Poles
3 Pole

Control Circuit
AC operated

Series
LC1D09

Mechanical Life
10 Million Ops

Filter Tuned
5th Harmonic

Condition
New

Frame Size
D09

Auxiliary Contact
1NO+1NC

Coil Voltage Range
110-240V AC

Contactor Type
AC Power Contactors

LC1D09 AC Control Power Contactor Trade Information

Minimum Order Quantity
5 Units

Payment Terms
Cash in Advance (CID), Cash Advance (CA)

Supply Ability
1000 Units Per Month

Delivery Time
7 Days

Main Export Market(s)
Asia

Main Domestic Market
All India

About LC1D09 AC Control Power Contactor

LC1D09 AC Control Power Contactor is designed for switching and controlling electrical circuits in low voltage applications up to 690V AC. It is manufactured by Schneider Electric, a leading company in the production of electrical equipment. The LC1D09 AC Control Power Contactor is a three-pole device with a current rating of up to 9A. It is suitable for use in various applications, including motor control, heating, and lighting. The contactor is equipped with an auxiliary contact block, which allows for remote indication of contactor status and facilitates interlocking with other devices.

High-Performance and Durability

Designed with a mechanical life of 10 million operations and made from high-quality plastic and metal, the LC1D09 ensures exceptional longevity and reliability, even in demanding conditions. The integrated overheating protection and IP20 rating provide safety while maintaining high switching efficiency in three-phase electrical systems.

Versatile Electrical Solution

With a wide coil voltage range (110-240V AC), auxiliary contacts (1NO+1NC), and 5th harmonic filter tuning, this contactor addresses various application needs. Its compatibility with standard DIN rail mounting and screw terminals simplifies installation and integration into electric circuits for manufacturers, dealers, and distributors.

Efficient Control for Electric Applications

This contactor is optimized for low power consumption (3.5 VA hold) and a minimum power factor of 0.8, ensuring economical operation. Coupled with easy wiring, high protection level, and a matte surface finish, it fits seamlessly into electric control panels for effective switching and control.

FAQ's of LC1D09 AC Control Power Contactor:

Q: How do I install the LC1D09 AC control power contactor in my system?

A: The LC1D09 contactor features DIN rail mounting and screw-type connections, making installation straightforward. Simply mount the contactor onto a compatible DIN rail and connect wiring using the provided screw terminals according to your system's configuration.

Q: What are the primary benefits of using a 5th harmonic filter-tuned contactor like the LC1D09?

A: Filter tuning for the 5th harmonic helps reduce harmonic distortion in electrical systems, improving overall power quality and protecting sensitive equipment from potentially harmful voltage fluctuations or heat buildup.

Q: When should I consider using the LC1D09 as part of my electrical control system?

A: You should use the LC1D09 when you require efficient and reliable switching for three-phase applications with coil voltages between 110V and 240V AC, especially in environments where high mechanical endurance and low power consumption are priorities.

Q: Where is the LC1D09 contactor commonly applied?

A: The LC1D09 is widely used in industrial and commercial electric panels, motor starters, and load control systems across manufacturing plants, distribution networks, and power management setups in India.

Q: What process should be followed to maintain the LC1D09 for optimal performance?

A: Regular visual inspections for dust accumulation, secure wiring, and proper ventilation are recommended. Ensure that the operating temperature remains within -5C to +60C and check the IP20 protection for any possible ingress to maintain the contactor's efficiency.

Q: How does the integrated overheating protection work in the LC1D09 contactor?

A: The contactor is equipped with an integrated overheating protection mechanism that prevents excessive temperature rise, safeguarding both the device and connected equipment from heat-induced failures or operational interruptions.
