Schneider Compact NSX Circuit Breakers

Schneider Compact NSX Circuit Breakers Specification

Rated Short Circuit Making Current
Upto 154kA

Mechanical Life
Up to 20,000 cycles

Breaking Capacity
25kA to 70kA

Phase
Single Phase

Rated Short Circuit Breaking Current
Upto 70kA

Product Type
High Voltage

Installation Options
Fixed, Plug-in, and Withdrawable

Function
Electric

Poles Number
3

Rated Voltage
690V AC

Rated Current
16A to 630A

Rated Frequency
50/60 Hz

Curves
B, C, D

Temperature Protection
Integrated Thermal & Magnetic Protection

Weight
Varies with Rating (Approx. 2.8 kg - 4.9 kg)

Color
Black

Operating Temperature
-25C to +70C

Neutral Protection
Optional Adjustable Neutral Pole

Arc Duration
< 6ms

Mounting Type
DIN Rail and Panel Mount

Control Options
Manual and Remote

Accessories Support
Auxiliary Contacts, Shunt Trip, Under-voltage Trip, Alarm Switch

Compliance Standards
IEC 60947-2

Trip Unit Type
Electronic and Thermal Magnetic

Terminal Type
Screw Terminals / Cable Lugs

Protection Class
IP40 (as standard), IP54 with Enclosure

Rated Insulation Voltage
800V

Schneider Compact NSX Circuit Breakers Trade Information

Minimum Order Quantity
5 Units

Supply Ability
100 Units Per Week

Delivery Time
3 Days

Main Domestic Market
All India

About Schneider Compact NSX Circuit Breakers

Access the preeminent Schneider Compact NSX Circuit Breakers at a reduced price, designed with astounding reliability and advanced protection features. Distinguished by IEC 60947-2 compliance, these breakers suit demanding requirements with manual and remote control options. Operate safely across -25C to +70C, mount on DIN rail or panels, and leverage support for a variety of accessories. With rapid arc duration (<6ms), robust IP40/IP54 protection, and rated insulation up to 800V, the NSX series ensures secure electric operation for dealers, distributors, manufacturers, suppliers, traders, and wholesalers in India.

Commercial Versatility for Electric Applications

Schneider Compact NSX Circuit Breakers are ideal for a wide range of commercial uses, from industrial infrastructure to commercial buildings. Designed for effective electric protection and operational reliability, they are widely used in power distribution, panel boards, and critical energy sectors. Their flexible installation options and outstanding safety standards make them suitable for application on-site in factories, utility substations, and large-scale establishments, supporting efficient and secure power management.

Prompt Sample Availability and Packaging Details

To facilitate domestic market demands, Schneider Compact NSX Circuit Breakers are available with quick dispatch options. Sample requests are welcomed to help clients assess suitability. Products are securely packaged to minimize expenditure on handling and damage prevention. Delivery times are streamlined to align with client schedules, ensuring you can rely on efficient supply, whether you're a small trader or a large-scale distributor seeking reliable shipment and prompt fulfillment.

FAQ's of Schneider Compact NSX Circuit Breakers:

Q: How does the Schneider Compact NSX Circuit Breaker support both manual and remote control?

A: The Compact NSX Circuit Breaker provides flexible operation through options for manual handling as well as remote actuation, catering to various control needs in electric installations.

Q: What are the main benefits of using Schneider Compact NSX Circuit Breakers in commercial environments?

A: These circuit breakers offer distinguished safety, quick arc suppression, reduced downtime, and support a wide current range, making them suitable for diverse commercial and industrial applications.

Q: When is it recommended to use auxiliary accessories with the Compact NSX breakers?

A: Auxiliary contacts, shunt trips, under-voltage trips, and alarm switches are recommended when additional functions such as signaling, remote tripping, or enhanced protection are required.

Q: Where can Schneider Compact NSX Circuit Breakers be installed for maximum safety?

A: Designed for both DIN rail and panel mounting, these breakers can be installed in power distribution boards, switchgear panels, and control centers, ensuring secure operation in commercial or industrial sites.

Q: What is the process to obtain a sample and how long does delivery take?

A: You can request a sample through official channels. Once ordered, samples are quickly dispatched and typically delivered within a short period, depending on domestic logistics arrangements.

Q: How does the integrated thermal and magnetic protection enhance device performance?

A: Integrated thermal and magnetic protection ensures rapid response to both overloads and short circuits, thus providing distinguished and dependable safeguarding for your electrical systems.
